KD Dual System Series Top mounted Air Conditioner
The KD dual system series overhead air conditioner adopts a dual cooling and heating system working mode, which can adopt single system working mode or dual system simultaneous working mode. It can be used for energy saving according to different scenarios. The overall height is only 243mm, and it adopts a dual fan exhaust heat dissipation mode, high-power heating system, and ultra strong air supply mode. It is suitable for large space vehicles, yachts, mobile houses, and rail transit.
|
Model |
KD-60DZ |
KD-72DZ |
||
|
Name |
Unit |
Parameter |
Parameter |
|
|
Cooling Condition |
Customized Cooling Capacity |
W |
6000 |
7200 |
|
Rated Cooling Power |
W |
3350 |
3500 |
|
|
Rated Current |
A |
15.23 |
15.9 |
|
|
Heating Condition
|
Customized Heat |
W |
5000 |
5000 |
|
Rated Heating power |
W |
5500 |
5500 |
|
|
Rated Current |
A |
25 |
25 |
|
|
power supply
|
single phase，220V/240V 50Hz |
single phase，220V/240V 50Hz |
||
|
Normal Operating Environment |
℃ |
-45~45 |
-45~45 |
|
|
Temperature Range |
℃ |
16~30 |
16~30 |
|
|
Refrigerant |
R410A |
R410A |
||
|
Refrigerant Charge |
g |
1300 |
1350 |
|
|
Weight |
Kg |
88 |
95 |
|
|
External Dimensions |
Mm |
1245(L)*1275(W)*243(H) |
1275(L)*1275(W)*243(H) |
|
